| Categories | TV Set Top Box |
|---|---|
| Brand Name: | Colable |
| Model Number: | COL3205 |
| Place of Origin: | Made in China |
| MOQ: | 1 set |
| Price: | Negotiation |
| Payment Terms: | T/T (Wire Transfer), Western Union etc |
| Supply Ability: | 10000sets per Month |
| Delivery Time: | 2-5 working days |
| Packaging Details: | Standard Export Carton with foam |
| Input: | HD QAM STB Annex B Box |
| Output: | HDMI, CVBS, SCART |
| USB: | Support |
| Video Decoding: | MPEG-2. MPEG-4 AVC/ H.264 |
| Audio Encoding: | MPEG-1/2/3, AAC, AC3(optional) |
| Resolution: | 1920x1080p/i, 1280x720p, 720x576p/i |
| Video Format: | PAL，NTSC，Auto |
| Bandwidth: | 6/8 Mhz (optional) |
| Applications: | Digital Free and Encryption System |
| Company Info. |
| Colable Electronics Co., Ltd. |
| View Contact Details |
| Product List |
Model: COL3205 HD QAM STB Annex B Box
Digital TV Receiver Decoder for Home Hospital Use
Features
Specification
| System | Main chipset: | HI3716MV310 |
| Main Frequency: | 1GHz | |
| FLASH Memory: | 1/2Gbit | |
| DDR Memory: | 2/4Gbit | |
| Tuner: | TDA18250B | |
| Demo Chip: | Built-in | |
| Composite Audio | Audio output Level: | ±4dBuv |
| Signal Distortion: | ≤1.2% | |
| Amplitude frequency performance: | +1/-2dB(60Hz-18kHz) | |
| Volume Control: | 32 Level Range | |
| L/R Crosstalk: | ≤-70dB | |
| Audio S/N(unweighted): | ≥70dB | |
| L/R Phase error: | ≤0.2 rad(60Hz-18Hz) | |
| L/R Level error: | ≤0.5dB(60Hz-18kHz) | |
| Composite Video | Video output level: | 700±30mVp-p |
| Video synchronous Level: | 300±20mVp-p | |
| Differential gain: | ≤5.5%p-p | |
| Differential phase: | ≤3.5rad | |
| Video S/N(weighted): | ≥56dB | |
| Luminance Nonlinearity: | 4.0/0% | |
| Chr/Lum Gain Inequality: | ±5% | |
| Chr/Lum Delay Inequality: | ≤14ns | |
| K coefficient: | ≤2% | |
| Line-synchronization Ieading jitter: | ≤13 | |
| Amplitude frequency performance: | 0.5/0.4dB(≤4.8MHz);0.5/-0.9dB(≥5.5MHz) | |
| Input parameters | Input frequency range: | 47MHz~1GHz |
| Channel bandwidth: | 8MHz | |
| RF input impedance: | 75Ω | |
| RF input reflection loss: | ≥8dB | |
| Demodulation: | 16/32/64/128/256 QAM | |
| Symbol rate: | 3.6~6.952Mbaud | |
| Min input Level: | ≤38dBuv(64QAM);≤43dBuv(256QAM) | |
| Max input level: | ≥100dBuv(64QAM);≥100dBuv(256QAM) | |
| C/N threshold: | ≤24dB (64QAM);≤31dB (256QAM) | |
| Frequency capture range: | ±600kHz(64QAM);±150kHz(256QAM) | |
| Decoder | Video decoding format: | H.264BP/MP/HP@level4.1;MPEG-1; MPEG-2MP@HL;MPEG-4 SP@L0-3 |
| Image decoding format: | JPEG Baseline;MJPEG Baseline;PNG | |
| Aspect ratio | 4:3;16:9 | |
| Video output: | PAL/NTSC self adaptive | |
| Video resolution: | 480i;480p;576i;576p;1080i;1080p | |
| Audio output | Right/left sound channel/stereo/mono | |
| Interface | IF input: | 1×F type(Female) |
| IF loopout | 1×IEC169-1 Male | |
| Analog audio output | 2×RCA | |
| Analog vedio output | 1×RCA | |
| Y PbPr output: | Group1,RCA interface | |
| HDMI interface: | 1×HDMI1.4 | |
| Digital audio: | 1×S/PDIF(fiber) | |
| RS232interface: | 1×DB-9(Female) | |
| USB: | 2×USB2.0 | |
| Internet port: | 1×RJ45(10/100M self-adaptive interface) | |
| IR interface: | 1×AUX | |
| IC CA card: | 1×ISO7816 | |
| Front panel | LED display: | Power,standby |
| Channel display: | 4-digit | |
| Front panelkey: | Power,channel+/-,volume+/-,ok,menu | |
| RF receiver | 38KHz,NEC encoding | |
| Power | Input voltage: | 220V AC |
| Input frequency: | 50Hz | |
| Standby power consumption: | ＜1W | |
| Power consumption: | ＜10W |
Digital IPTV, CATV+IPTV System
Certificates
Colable Electronics co.,ltd
Specialize in Digital TV broadcasting equipment for more than 10
years, and experienced in Digital Cable/Satellite/ Terrestrial tv
broadcasting solution and system, If you have any questions and
ideas, please no hesitate to contact us!
Please feel free to ask if you have any questions. Welcome !!!
|
