Opto - Edu Digital Comparison Microscope A18.4902 With Sony Imx274 Coms Sensor

Categories Forensic Comparison Microscope
Brand Name: CNOEC, OPTO-EDU
Model Number: A18.4902
Certification: CE|Rohs
Place of Origin: China
MOQ: 1 pc
Price: FOB $1~1000, Depend on Order Quantity
Payment Terms: T/T, West Union, Paypal
Supply Ability: 5000 pcs/ Month
Delivery Time: 5~20 Days
Packaging Details: Carton Packing, For Export Transportation
Applications: Student|school|Laboratory|Research
Image Sensor: SONY IMX274 COMS Sensor
Illumination: LED
Maximum Resolution: 3840 x 2160 (8,294,400 pixels)
Theory: Comparison Microscope
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Opto - Edu Digital Comparison Microscope A18.4902 With Sony Imx274 Coms Sensor

1.Super Wide Dynamic, Super Low Intensity Of Illumination
2.Pixels Comparison Output Comparison Results Automatically
3.Overlap, Cut, Full Field Of View, Transparency Settings
4.Multiple Windows To Preview Dynamic And Static Images
5.Dual Lens 8.0MP+8.0MP Preview And Snapshot
6.7 Colors Illuminations To Display More Details
7.X/Y/Z/R Axis Fine Tuning Workbench
8.Extra-hard Wear-resistant Aluminum Alloy Housing
9.Dedicated Measurement Software

A18.4902 Digital Forensic Comparison Microscope Specification
Hardware configuration
Image SensorSONY IMX274 COMS Sensor
Expose ModeRolling Shutter .
Maximum Resolution3840 x 2160 (8,294,400 pixels)
Sensor Optical Format1/2.5''
Pixel Size1.62μm x 1.62μm
Dynamic Range>80dB
SNRmax≥50dB
Spectral Charactristics380-650nm
Exposure CapabilityReal-time Auto, Single Auto, Manual Adjustment
White BalanceReal-time Auto, Single Auto, Manual Adjust R G B Seperately
Record FormatSnapshot
Picture Format: JPG
Resolution: 3840x2160
Record
Video Format: MOV
Resolution: 3840X2160@25FPS,2592X1944@25FPS,2048x1536@25FPS
Optical Parameters
Optical Magnification Of Lines0.83x~10x
Optical Resolution Of Lines(um)5um
Working Distance(mm)72mm
Observation Range(mm)0.65x0.36~8.2x4.6mm
Comprehensive MagnificationFull Screen Display On A 21-inch 16:9 Minitor:57x~715x
Full Screen Display On A 17-inch 16:9 Minitor:46x~578x
Working StageSquare Manual Working Stage 120*120*43mm, Moving Range 55*55*55mm
Joint Left/Right Moving Range 80mm, Joint Up/Down Range 150mm
Clamp Working Stage Dia.100mm, 360° Rotatable
Round Titable Working Stage Moving Range 0-14.5mm, 45°-90° Inclined, 360° Rotatable

Ring LEDs( Coaxial & Diffuse LED ) Parameters
Power<3W
Input VoltageDC 5V
Dimming Method0-100% Linear Adjustment
Centric BrightnessCoaxial: ≥12000LX (Height 100mm)
Diffuse Reflection: ≥42000LX (Height 100mm)
Number Of LEDsCoaxial Light: 13 Small Angle Highlighting Lamp Beads
Diffuse Light: 40 Bright White LEDs
Color Temperature5000K~5500K
Adjustment MethodSeparate Control (Independently Controlled By One Knob For One Kind Of Light)
Seven-color LED Parameters
Power<3W
Input VoltageDC 5V
Dimming Method0-100% Linear Adjustment
Comprehensive MagnificationRed: 610um
Yellow: 600um
Warm White: 586um
Green: 528um
White: 494um
Purple: 458um
Blue: 470um
Adjustment MethodBrightness And Light Switching Are Controlled By Different Knobs
Software Environment
Windows System DemandMicrosoft ® Windows ® XP / 7 / 8 /8.1/10(32 & 64 bit)
CPU: Dual-core 3.0 GHz Or More CPU
Memory: 4G Or More
Network:10/100/1000Mbps Compatitable Interface
At Least 10 GB Available Hard Disk Space
Operating Environment
Operating Temperature0℃~ 40℃
Storage Temperature-20℃~ 60℃
Operating Humidity30~60%RH
Storage Humidity10~80%RH
