8 channel 3GSDI to Fiber Digital Video Converter with RS485 data customized services sdi to fiber converter

3G-SDI Transmitter & Receiver Kit Over Singlemode Fiber ST/PC 20km,180mm x 123mm x 30mm

Product Description

System Design Fiber Optic Video Transmitter & Receiver

SDI series can transmission 1/2/4/8-Channels

SD-SDI/HD-SDI/3G-SDI video over 1 single core fiber.

Single-Mode or Multi-Mode

SD-SDI/HD-SDI/3G-SDI units are designed to support LC /PC Optical connector

We will offer free patch cord + adaptor for your request for SC/PC or ST/PC or FC/PC optical

connector.

The Transmission distance Range according to the Optical Budget.

Manufacturer's default standard is single mode 20Km .

Features

•1/2/4/8 Channels Video of SD-SDI/HD-SDI/3G-SDI can be transmitted via 1 single fiber

• The Max rate of work is 3.2Gb/s

• Support SMPTE 292M (2.9Gb/s) clock recovery

• Support standard of 1.485Gbps/M(HD-SDI/ SD-SDI),SMPTE 425M 3Gb/s Mapping(3G-SDI),SMPTE 424M 3Gb/s serial interface(3G-SDI)

• Out wavelength range is 1310nm,1550nm and 16 other kind of CWDM wavelength ( comply with ITU-T G.694.2)

• Automatic cable equalization ,used for all rate below 3.2 Gb/s(Belden 1694A)

• LED Status Indication to monitor the working conditions

• Video transmission system can support many application branches structure

•The fiber port Support SFP transceiver hot-plugged

•The SDI video format support:

625/25 PAL

525/29.97 NTSC

525/23.98 NTSC

720p50,720p59.94

1080P 23.98/24/30/50/60

1080i 23/24/30/50/59.94

Typical application

Remark

•The Optical Power Budget fit Multi-mode(62.5/125m),Single-Mode(9/125 m).

•When using 50/125 m multimode fiber, subtract 3 dB from the optical power budget.

•Optical transmission distance is limited to optical loss of the fiber and any additional loss introduced by connectors, splices and patch panels.

•Maximum transmission distance is also limited by fiber bandwidth.

•Power adapter for stand-alone units is manufactured by third party .Power adapter included US, European, UK or Australian power plug.

•Please feel free to contact factory for any special requirement and customization

Technical parameters

Fiber	Connector: FC/ ST/PC Wave length: 850nm/1310nm/1550nm Transmission distance: multi-mode 0-2km, single-mode 0-25km, 0-60km, 0-120km ; Transmitting power: better than -6dB Receiver sensitivity: better than -18dB Optical dynamic range: 12dB Optical maximum loss: 12dB Fiber: single-mode/multi-mode fiber, single fiber
Fiber Transmission Distance is limited by optical circuit loss and additional loss as a result of connectors, fittings and patch panel. Transmission distance may also be limited by fiber optic bandwidth.
Video interface	Video Bandwidth: 5Hz~10Hz Rate input & output Level: 1Vp-p Sampling Frequency: 16.4M (typical value) Signal Impedance: 75 Ω Signal Interface: BNC/PAL/NTSC/SECAM Differential Gain (DG): <1.3 %( typical value) Differential Phase (DP): <1.3° (typical value) Signal Noise Ratio (SNR): 63dB
Data interface	Data Interface: RS-232,RS-422,RS-485,TTL Data Mode: NRZ,Manchester,Bi-phase Data Rate: 110bps-115.200Kbps Interface Port: RJ45
Power	Power supply:AC180V ~ 260V;DC –48V;DC +24V Power consumption: ≤5W
Dimension	product size:103X93X28(WXDXH) simple packing:200X176X55(WXDXH)
Working environment	Working temperature: -10°C ~ 50°C Working Humidity: 5%~95 % (no condensation) Storage temperature: -40°C ~ 80°C Storage Humidity: 5%~95 % (no condensation)

Packaging & Shipping

LM-HSD2 Video HD HDMI Displayport to SDI Converter With Scaler, Convert HDMI to SDI Embedded Audio

Our Services

Welcome to inquire!

Ho-Link Technology Co.,Ltd

China factory supply 1080P sdi multiplexer displayport to sdi converter

Company Information

Company Profile

Ho-link Technology Co., Limited is a leading manufacturer of fiber optic transmission products in China. We manufacture full range fiber optic transmission products , from Media converter, Video converter, to Optical transceiver and POE switch. Besides, we provide OEM/ODM service for many famous companies in Telecom industry all over the world.

Every month, we can turn out 10,0000 units of above products. Before production, our raw materials are checked again to make sure they are compliant with RoHS Directives. And all our output is CE and FCC-marked, finding good markets in many countries and regions including United, Kingdom,

Spain,Italy,Poland,Turkey,US,Canada,Brazil,Australia,Indonesia,Singapore,Malaysia,Vietnam and India.

Welcome to source high quality products at competitive prices from us.

Company Photo

Product Tags:


*From:	Your email address is incorrect!
*To:	Ho-link Technology Co., Limited
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Categories	3G SDI Video to Fiber Converter
Brand Name:	Ho-link/OEM
Model Number:	HL-8V1D-20T/R/3G-SDI
Certification:	CE RoHS FCC
Place of Origin:	China
MOQ:	1 Pair
Price:	Negotiable
Payment Terms:	T/T or western Union or Paypal
Supply Ability:	6000pcs per month
Delivery Time:	3 working days after received your payment
Packaging Details:	Neutral /Standard/Customized packing
Product Name:	3G SDI to fiber converter
Fiber module:	3G SFP
Working temperature:	-10°C ~ 50°C
Power consumption:	≤5W
Interface type:	FC/SC/LC
Signal Impedance:	75 Ω
Data:	RS485
Wavelength:	1310/1550nm (Option)
