Truck Mounted Drilling Rig Serva TPD 600 Triplex Plunger Pump
SERVA TPD 600 TRIPLEX PLUNGER PUMP
SERVA TPD 600 triplex plunger pump is used for cementing and acidizing service. Its short length design allows back-to-back placement of two pumps on the unit with less than 102" total width.
| Maximum input horsepower | 600 BHP |
| Maximum rod load. | 100,000 lbs |
| Stroke length | 6" |
| Gear ratio | 4.6:1 |
| Plunger | 3" to 4.5" |
| Approx. length | 50.25" (1,276 mm) |
| Approx. width | 52.93" (1,344 mm) |
| Approx. height | 23.88" (607 mm) |
| Approx. weight, dry | 4,600 lbs |
Heavy-duty crankshaft construction
Wider heavy-duty main bearing
Proprietary crosshead coating
Left or right gear box mounting
Forged alloy steel or UltraLast ® stainless steel mono-block fluid end with removeable stuffing box
Left or right suction and discharge connections
High performance header-ring style packing
|
