RoHS Certified Moulded Case 50Hz Automatic Power Transfer Switch

Categories Automatic Power Transfer Switch
Brand Name: FEEO
Model Number: FTSM
Certification: CE/CCC/RoHS
Place of Origin: China
MOQ: 1PC
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000pcs per week
Delivery Time: 7days
Packaging Details: 8pcs per carton
Rated Working Voltage: 400V
Controling Voltage: 230V
Rated Short Circuit Breaking Capacity: 3KA
Rated Insulation Voltage: 800V
Transfer Time: <3S
Frequency: 50/60HZ
ATS Level: CB Class
Standard: IEC60947-1
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

RoHS Certified Moulded Case 50Hz Automatic Power Transfer Switch

CE/CCC/RoHS Certified Moulded Case Dual Power Transfer Switch 400V 50Hz


FTSM series automatic transfer switch are mainly composed of power

conversion actuator, circuit breaker and controller. This dual power switch

with automatic, manual, power indicator, normal switch indicator, ready

switch indicator working state. Switch's features are small volume, long life,

low power consumption, light weight, stable work, easy to use and so on.


♦ Technical Data

ModelFTSM-63FTSM-125FTSM-250FTSM-400FTSM-630
StandardGB/T 14048.11
Electrical Characteristic Parameter
Shell Frame Current63A125A250A400A630A
Rated Current In(A)

10,16,20,25,

32,40,50,63

25,32,40,50,

63,80,100,125

100,125,140,160,

180,200,225,250

225,250,315,350

,400

400,500,630
Rated Operating Voltage UeAC 400V 50Hz
Rated Insulation Voltage UiAC 500VAC 800VAC 800VAC 800VAC 800V
Rated Impulse Withstand Voltage Uimp6kV8kV8kV8kV8kV
Poles3P , 4P
Life (times)60006000600040003000
Use CategoryAC-33iB
Electrical LevelCB Class
Protection LevelIP30
Control Characteristic Parameter
Rated Control Supply Voltage UsAC 230V 50Hz
Switching Time≤3s≤3s≤3s≤4s≤4s


♦ Installation

When installing wiring, normal power N should be access to normal power supply circuit breaker QN, ready
power R should be access to ready power supply circuit breaker QR. When QN and QR is 4 poles circuit
breaker, wiring mode according to the wiring diagram, which QN and QR's 1, 3, 5 are three-phase ( A, B, C )
into line terminals, 2, 4, 6 are three-phase outgoing line terminals, 7 is zero line (N) into line terminal, 8 is
zero line outgoing line terminal. If the use of 3 poles circuit breaker, the normal power N's zero line (NN) and
ready power R's zero line (NR) must be respectively received on 3 poles special connection zero line terminal.
Specific see wiring diagram. Dual power transfer switch automatic controller's work power supply circuit breaker
QN and QR's into line terminal A and zero line N, in the automatic power switch installation, wiring process,
Do not let the local controller to forget to connect the signal line, touch off or short circuit and so on,
otherwise can not work.
