| Categories | Dual Mode ONU |
|---|---|
| Brand Name: | V-solution |
| Model Number: | V2801RGW |
| Place of Origin: | Guangdong, China |
| MOQ: | 1 pcs |
| Price: | Negotiable |
| Payment Terms: | Negotiable |
| Supply Ability: | 1000 pcs/day |
| Delivery Time: | 3-5 days |
| Packaging Details: | Carton |
| Product: | Gpon ONU Router with WiFi |
| Use: | FTTx |
| WiFi: | IEEE802.11b/g/n, 2.4G |
| Antenna Type: | 2T2R |
| Chipset: | Realtek |
| Function: | Firewall / QoS / VPN |
Dual Mode ONU 1GE+WiFi ONU For Fiber Optic Network Router Modem Ont
Product Description
V2801RGW is based on the stable and mature GEPON technology, which has high performance/price ratio, and the technology of layer 3 Ethernet switch as well.It is highly reliable and easy to maintain, with guaranteed QoS, and fully compliant to IEEE 802.3ah EPON standards.
V2801RGW is realtek chipset Mini GPON Routing ONU modem designed for fulfilling FTTH ultra-broadband access request of home and SOHO users. It suports NAT/firewall and the technology of 802.11n WiFi (2T2R) so on functions.
Key Features
Specifications
| LED | Mark | Status | Description |
| Power | POWER | On | The device is powered up. |
| Off | The device is powered down. | ||
| Optical signal loss | LOS | Blink | Device does not receive optical signals. |
| Off | Device has received optical signal. | ||
| Registration | REG | On | The device is registered to the PON system. |
| Off | Device is not registered to the PON system. | ||
| Blink | Device registration is incorrect. | ||
| Interface | LINK/ACT | On | Port is connected properly (LINK). |
| Off | Port connection exception or not connected. | ||
| Blink | Port is sending or/and receiving data (ACT). | ||
| WiFi | WiFi | On | WiFi running |
| Off | WiFi not working |
| Technical item | 1GE |
| PON interface | 1 G/EPON port(EPON PX20+ and GPON Class B+) Wavelength:Tx1310nm,Rx 1490nm SC/UPC connector Receiving sensitivity: ≤-28dBm Transmitting optical power: 0~+4dBm Transmission distance: 20KM |
| Downlink | 1 x 10/100/1000Mbps auto adaptive Ethernet interfaces.10/100/1000M Full/Half, RJ45 connector |
| WLAN | Compliant with IEEE802.11b/g/n Operating frequency: 2.400-2.4835GHz support MIMO, rate up to 300Mbps Support: multiple SSID Channel:13 Modulation type: DSSS,CCK and OFDM Encoding scheme: BPSK,QPSK,16QAM and 64QAM |
| LED | 5, For Status of POWER,LOS,PON,LAN,WiFi |
| Operating condition | Temperature: 0℃～+50℃ Humidity: 10%～90%(non-condensing) |
Storing condition | Temperature : -30℃～+60℃ Humidity :10%～90%(non-condensing) |
| Power supply | DC 12V/0.5A |
| Power consumption | ≤6W |
| Dimension | 120mm×78mm×30mm(L×W×H) |
| Net weight | 0.15Kg |
