New Series 22mm 20-500V AC Digital Voltmeter Volt Meter Red Green Yellow Mini LED Indicator Panel Light

1. Model:

AD101-22VMS indicator light (pilot light) Volmeter

2. Features:
Lens Material: PC;
Lighting Source: LED;
Color of lamps: red, yellow, blue, green, orange, white;
Volt.20V--500V;
Color of Lens: Red, Orange, Blue, Green
Nature of supply: AC ;
Rated Temp : T90;
Life of continuous working: Typically over 30,000 hours. The end of life for a lamp is not usually a sudden failure;
Certification: ISO9001, CE,
Reasonable price and efficient services.

3. Main technical parameters
Environmental Temperature : -25℃~+55℃

Working under vibration frequency 2-80Hz,acceleration at 0.7g;
Relative Air Humidity: ≤98%;
Pollution rank is three grade and installation category is III;
Protection Degree: Head IP65(OEM could be IP67);
Voltage of working frequency: 2.5kV (AC valid value), 1min;
Leakage Index: CT1≥100;
Frequency: AC 50-60Hz

Notice : Can not used in the electric environment with frequency conversion, high frequency, strong harmonic interference signal.
