DPP Automatic Blister Packing Machine Forming Packaging Tablet Capsule Pill

Categories Blister Packing Machine
Brand Name: Rich Packing
Model Number: DPP-260R
Certification: CE/ISO 9001/SGS
Place of Origin: Guangzhou, China
MOQ: 1 pcs
Price: Negotiated price
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 50 pcs/month
Delivery Time: 5-8 working days
Packaging Details: Standard export wood case the machine is first wrapped with a transparent film, and then bound in a wooden box to ensure the safety of the machine during transportation.
Production capacity: 236,000 pcs/hour
Number of blanking: 20~180 boards/min
Maximum forming area: 160×250*15mm
Maximum depth: 26mm (can customized)
Standard Travel Range: 40-160mm
Standard plate: 80*57mm
PVC thickness/width: 260×0.15-0.45mm
PTP aluminum foil thickness/width: 260×0.02-0.03mm
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

DPP Automatic Blister Packing Machine Forming Packaging Tablet Capsule Pill

DPP Automatic Blister Packing Machine Forming Packaging Tablet Capsule Pill


Thickness and Width260×0.02 - 0.03mm
Dialyzing Paper data50~100g*260mm
Vacuum of blister packing machine 260R0.4MPa-0.6MPa
gas consumption0.2m3/min
Noise of blister packing machine 260R<75dBA
Mold CoolingRuning or circulating water It is recommended to use constant temperature cold water 60 L/H


The Blister Packaging Machine Automated we Rich Packing provide long as to 3 years warranty short leading time in ten days, is a most popular machine with a wide range of applications: for as an important parts of the 260r DPP automatic blister packaging machine, the feeding motor and the servo motor are selected from Chinese Taiwan Delta brands. The servo motors have extremely high traction accuracy, and it will be zero error in the traction precision.


Even if the machine stops suddenly, the traction position will not appear to backwards. The operating does not need to be aligned, and the operation is very easy. The PVC material feeding motor has the characteristics of accurate material feeding and fast machinery running speed.
The PLC smart touch screen of the blistering machine automatic is selected from Siemens from Germany, and the module designed is selected from Japan's Omron. The PLC screen and its modules of the blister packaging machine fully automatic are more convenient for data management. At the mean time, it also has a data programming functions, that is convenient for customers to operate and to manage, and has a highly degree of integration.


The emergency stop buttons of the Blister Packaging Machinery Automated is made by France Schneider. When the machinery fails, please press the emergency stop button to stop the machine at once.
