DDS5558 Gomelong 3 Phase 4 Wire Prepaid Electric Energy Meter

Categories Prepaid electricity meter
Place of Origin: Zhejiang, China
Brand Name: GOMELONG
Model Number: DTSY5558
Display Type: Analog and Digital
Phase: Three Phase
Measuring Energy Range: 0-999999
Accuracy Class: 1.0 or 2.0s
Output Voltage: 110V,220V,230V,240V
Operating Temperature: -20℃-55
Dimensions: Standard
Colver: White
Display: 7 Digits LCD
Color: White
Certificate: ISO9001
Frequency: 50HZ/60HZ
Standard: IEC62053-21
Product name: Wholesale 3 Phase 4 Wire Prepaid Electric Energy Meter
Material: PC+ Uv
OEM: Allowed
Packaging Details: 15kgs/carton
10pcs one carton
Port: Ningbo
Supply Ability: 100000 Piece/Pieces per Month Wholesale 3 Phase 4 Wire Prepaid Electric Energy Meter
Price: $30.00 - $40.00/Pieces
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

DDS5558 Gomelong 3 Phase 4 Wire Prepaid Electric Energy Meter

Wholesale 3 Phase 4 Wire Prepaid Electric Energy Meter

Model DDSY/DTSY5558 Single/three phase electronic prepayment active energy meter is a kind of active energy meter which purchase electricity by IC card, electric energy measuring, load control and using electricity management. Th e meter completely accord with relevant technical requirements of class 1 three phase active energy meter stipulated in international standard IEC 62053-21. It can accurately and directly measure 50Hz or 60Hz active energy consumption from three phase four wire AC electricity net, it is used for installed in meter box indoor or outdoor. This meter has LED monitors shows power. It has following features: Good reliability, light weight, specious nice appearance, convenient installation, etc.


Feature

Payment use ic card prepaid automatic power-off when low credit.

Power–off alarm when electricity shortage, remind users to buy electricity timely

Register display the total power consumption

Overload alarm


Technical Parameters

Specification

DDSY5558

DTSY5558

Accuracy

Active

Class1.0

Class1.0

Reactive

Optional

Voltage

Rated

110/120/220/230/240V

3x57.7/100V,3x220/380V

3x230/400V,3x240/415V

Range

0.9Un~1.1Un

0.9Un~1.1Un

Limit

0.8Un~1.2Un

0.8Un~1.2Un

Frequency

50/60Hz

50/60Hz

Current

Range

1.5(6), 5(30), 10(50), 15(90), 20(100), 5(40), 5(100)A

3x1.5(6), 3x 5(30), 3x 10(50),

3x 15(90), 3x 20(100), 3x 5(40), 3x 5(100)A

Starting Current

0.4%Ib

0.4%Ib

Constant

Active

1600imp/kWh

400imp/kWh

Reactive

Display

Type

LCD

Register

Digit

6+1

6+1

Power Consumption

Voltage Circuit

≤0.8W,10VA

≤0.8W,10VA

Current Circuit

≤4VA

≤4VA

Communication

Interface

Optical/Infrared/RS485 (Optional)

Optical/Infrared/RS485 (Optional)

Protocol

MODBUS,DLT/645,IEC1107

MODBUS,DLT/645,IEC1107

Temperature

Working Temperature

-45℃~+55℃

-45℃~+55℃

Storage Temperature

-40℃~+70

-40℃~+70

Humidity

≤90%

≤90

Protection

IP54

IP54


Dimension&Wiring Diagram


Plz pay attention:One meter equiped one card for free,vending system will be provided with a CD,Card reader is charged separately,If you buy 500 units ,the card reader will be free.
