Three Layer Paper Drinking Straw Making Machine Degradable Drinking Straw Machine

Categories Paper Straw Machines
Brand Name: Fect
Model Number: PF-01 paper straw machine
Certification: CE
Place of Origin: China
MOQ: 1 SET
Price: USD 11494~13890
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 35 Set per month
Delivery Time: within 35 working days after payment confirmed
Packaging Details: Wooden case / Degradable three layer paper straw making machine
Production name: Degradable three layer paper straw making machine
paper layer: 3
Paper Straw Inner Diameter: 4 -12mm
Wall Thickness: 0.3-1mm
Winding Speed: 0-40meters/min
Working Space: 7000*5000mm
Cutting System: Multi-blades (5 pcs)
Power Supply: 380V/3Phase/50Hz
Straw Collector: L type auto collector
Gluing Way: Single/Double sides
Main Motor: 3.0KW
Weight: 1300kgs
Measurement: 3500*1500*1200mm
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Three Layer Paper Drinking Straw Making Machine Degradable Drinking Straw Machine

Degradable three layer paper straw making machine paper drink straw machine


paper straw machine


PF-01 Stainless Steel Paper Straw Machine including paper unwinding, gluing, twisting, cutting, conveying and collecting units(optional), equipped with 5 pcs round knife to cut off paper drink straw on line. It is suitable for making 4-12mm outer diameter paper drinking straws, stable speed up to 50m/min.


Degradable three layer paper straw making machine paper drinking straw machine


♦Application♦

This paper straw machine to make drinking straw is used for making various kinds of paper drinking straw.

♦Features♦

1.Adopting PLC man machine interface, stepless frequency speed adjustment, pc circuit control board

2. Cutting unit is multi-round cutter controlled by servo motor, synchronous tracing and cutting.

3. Automatically cut, automatically fall pipe, automatically change speed and revert;

4. Round knife cutting, incision more smooth, performance more stable;

5. With online multi-cut blades, no need secondary cutting, save labor and time.

6. Stainless steel gluing box, with polyurethane scraper and high carbon steel plastic knife, durable in use;

7. Machine supply of lubricant automatically.


♦Technical parameters♦


Technical Parameter
Paper Layer3 layers
Inner Diameter4 -12mm
Wall Thickness0.3-1mm
Winding Speed0-40meters/min
Cutting SystemMulti-blades (5 pcs)
cutting systemServo motor synchronism tracking cut
Gluing WaySingle/Double sides
Machine & PartsStainless Steel or Paint
Straw CollectorL type auto collector
Operator1-2 person
Speed ControlBy Inverter
Power Supply380V/3Phase/50Hz
Control System
Main Motor3.0KW
Motion controllerPanel Master
Touch ScreenPanel Master
Inverter3.7KW Schneider
Pneumatic ComponentsJingwei
Electric ComponentsSchneider
BearingHaerbin
Servo MotorSchneider
Screw Rod/sliderShangyin
Configuration
Paper Reel Stand & Glue Unit3 Layers
Belt5 Pieces
Mandrel Shaft2 Pieces
Useful Tool1 Set
Measurement & Weight
Measurement3500*1500*1200mm
Working Space7000*5000mm
Weight1300kgs

♦ FAQ ♦


Q: Do you factory accept customized configuration?

A: Yes. About electric parts, you could choose SIEMENS, Schneider, Delta and etc. For the machine device, web guiding, vedio monitor, pneumatic-unwinding loader,elctric-rewinding unloader, slitting station ratary die cutting station, lamination and waste rewinding are optional. For the specific combination, pls contact us.


Q: How does your factory do regarding quality control?
A: Quality is priority. We always regard great importance to quality controlling from the very small thing (even a small screw we will choose the best quality) from the beginning.


Q: What is your after-sales service?
A: Our after-sales service is first class. We have a powerful team to help you solve problems.The Warranty is one year and if the machine is damaged by natural not by human, we can send the new parts to you for free.


Q: What is the terms of payment you accept?
A: 30% T/T in advance, 70% T/T balance before delivery. We also accept L/C and Western Union.
