| Categories | Inverter TIG Welder |
|---|---|
| Brand Name: | JONE |
| Model Number: | TIG/MMA-200A |
| Certification: | CE |
| Place of Origin: | GUANGDONG,CHINA |
| MOQ: | 300 |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 70000 PCS /month |
| Delivery Time: | 4 WEEKS |
| Packaging Details: | CARTON |
| Price: | Negotiate |
| Type: | IGBT 1 PCB |
| AC Input Power Capacity(KVA): | 220V |
| Rated Input Power Capacity(KVA): | 7 |
| Input Frequency(Hz): | 50/60 |
| Non-load Voltage(V): | 56 |
| Output current range(A): | 20-200 |
| Rated Duty Cycle(%): | 60% |
| Efficiency(%): | 85% |
| Class of Insulation: | F |
| Protection class of case: | IP21 |
| Quick joint Size(mm): | 35-50 |
| Input power cable(m): | 1.8M |
| N.W./G.W.(kg): | 4.5/8.3kg |
| Accessories: | 4M WP-17 Black Torch、clamp、holder、 mask、brush、manual |
| Usage: | welding |
| Condition: | New |
| Machine Size(L*W*H): | 420*160*310 MM |
| Warranty: | 24Months |
Handy Inverter TIG Welder 160Amp Semi Automatic Tig Welding Machine
While TIG welding may not be the best option for all kinds of businesses, it has a lot of benefits. Some works that require multiple welds or require code requirements such as piping; nuclear work and high profile consumer products regularly require at least the primary weld in the pipe joint to be TIG for an efficient connection.
TIG welding is a good option for many manufacturing businesses. Its versatility allows it to handle a variety of different jobs, such as those involving pipes and tubing, consumer products, electrical fixtures and other high-profile projects. Welder pros typically recommend this method in the first place when dealing with heavy-duty applications that gear up for longer usage. This way you can relieve stress on your equipment by keeping these joints TIG welded instead of requiring ground welding after each weld.
technical parameter
| Model | TIG/MMA-200A |
| Type | IGBT 1PCB |
| Real Amp(A) | 160 |
| AC Input Voltage(V) | 220V(110V/220V can do) |
| Rated Input Power Capacity(KVA) | 7 |
| Input Frequency(Hz) | 50/60 |
| Non-load Voltage(V) | 56 |
| Output current range(A) | 20-200 |
| Rated Duty Cycle(%) | 60% |
| Efficiency(%) | 85% |
| Class of Insulation | F |
| Protection class of case | IP21 |
| Quick joint Size(mm) | 35-50 |
| Input power cable(m) | 1.8 |
| N.W./G.W.(kg) | 4.5/8.3KG |
| Machine Size(LxWxH mm) | 420*160*310 |
| Package(LxWxH mm) | 455*270*355 kraft paper box+ foam |
| Accessories | 1.8M 16mm2 200A holder |
| 1.2M 16mm2 300A clamp | |
| 4M WP-17 Black Torch | |
| Brush, Mask, Manual |
|
