Precision Micro Spot Welder Capacitor Discharge Spot Welding Machine Projection

Hwashi Precision Micro Spot Welder, Capacitor Discharge Projection Welding Machine

Description Of Precision Micro Spot Welder
Precision micro spot welder uses capacitor to store energy and to release instantaneous current. In the meantime, it concentrates large current to pass through a small point and then achieves welding effect (welding process passes through thousands of ampere current within 1/1000 second of time). Therefore, it can minimize the situation that the work piece being oxidized or mechanically deformed due to overheat during the process of welding. The output of the capacitor discharge spot welder that we produce is from 100WS to 18000WS. It is especially suitable for welding metals like red copper, bronze, brass, aluminum, silver and stainless steel, etc. Thus, this type of machine is widely applied to various kinds of industrial production and manufacturing.

Features Of Precision Micro Spot Welder
1. Effectively restrain the occurrence of welding spatter;
2. High working accuracy;
3. High degree of steel structure;
4. Low pressure of welding;
5. Stepless adjustment of electrode pressure range;
6. Stepless adjustment of electrode pressure stroke;
7. Flexible collocation of welding head. Indirect single-point, indirect double-point and direct single-point or direct double-point is all available.

Application Area And Samples Of Precision Micro Spot Welder
Welding of silver contact of low voltage appliances, welding of mini precise work pieces like crystal valve of chip, etc.

Technical Parameters Of Precision Micro Spot Welder
Micro Precision Type Capacitor Spot Welding Machine

Model	Welding Spot Manner	Input Voltage	Input Power	Capacitance	Output Heat	Welding Capability	Dimensions
	Single / Double	V	KW	μF	J	mm×Pieces	W*D*H (mm)
WL-CJ-0.5K	Direct single-point	220/1	0.5	2000	180	0.4×2	500*400*300
WL-CJD-0.5K	Indirect double-point	220/1	0.5	2000	180	0.4×2	500*400*300
WL-CJ-1K	Direct single-point	220/1	1	3000	380	0.5×2	500*400*300
WL-CJD-1K	Indirect double-point	220/1	1	2000	180	0.5×2	600*450*300
WL-CJ-2K	Direct single-point	220/1	1	4500	500	1.0×2	380*650*450

Company Introduction

ABOUT US

Hwashi company is a powerhouse in the world of automatic resistance welding equipment and industrial robots. We go beyond the conventional boundaries of welding machine manufacturer. We pride ourselves on being a comprehensive service provider, offering not only top-notch machine but also a dedicated team of specialists committed to providing global customers with reliable and customized solutions to meet their unique application needs.

What sets us apart is our team of over 40 specialists, each with over a decade of industry experience. They are the driving force behind our innovative solutions. With two solid decades in the industry, our welding equipment and robotic arms have proven their mettle across various industrial sectors. From home appliances, kitchen utensils, wires, and cables to lighting fixtures, metal hardware, electronics, and automotive parts. We've got quite the track record.

Our commitment to constant innovation and intensive research and development has earned us over 70 invention patents. Today, our portfolio includes industrial robots, automatic welding lines, spot welding machines, and other resistance welders, all of which have reached more than 80 countries and regions globally. Achieving an annual sales volume exceeding 25 million US dollars, our products' reliable performance has garnered acclaim from renowned international companies.

We take pride in our legacy of trust and excellence, and we're eager to extend our commitment to you. Give us the opportunity to showcase our dedication by providing you with nothing short of the finest solutions and services available.

Over the years, Hwashi has cultivated a large number of talented, dedicated and innovative Hwashi people. We have a professional

team of experts with rich experience in electrical engineering, mechanical design and welding technology.

Since its establishment 22 years ago, hwashi technology has traveled to all corners of the world, participated in more than

100 exhibitions and served more than 8,000 customers

FAQ:

Q1: what is the price of your machine?
Answer: our machines are customized for your requirements. If you want to get the appropriate

price, please provide us the following information.
* The material and thickness of your product
* The minimum and maximum size of your product
* The welding position of your products
* The automation level that you want to achieve
* It would be better if you can provide us the detailed product drawings so our engineer can come out with

the suitable technical proposal and price for you.

Q2: what is the warranty period of your machine?
Answer: our standard warranty period is one year after shipment. If you want to extend the warranty period,

there will be extra cost.

Q3: what if my machine damaged doing the warranty period?
Answer: firstly, our engineer will help you to diagnose the problem via online guidance. if any parts damaged

during the warranty period, we will send the parts to you for replacement free of charge. If you can not fix he

problem by replacement of the new parts, we will send engineer to your factory to help fixing the machine.

Q4: what is the delivery time of your machine?
Answer: it depends on the complexity of your machine. Most of our standard machine we got in stock, then

we can shape the machine with the seven days after receiving your payment. If you need the Customized

machine, normally it would take about 30-90 days to complete the machine.

Q5: can we send the sample to you for welding test?
Answer: yes. You can send us the samples for welding test and we will send you the pictures and videos

after the testing. If you need, we can also send the samples back to your country so you can check

the welding quality by yourself before ordering the machine.

Q6: can you provide us the machine drawings and technical proposal?
Answer: yes. After receiving your detailed requirement and product drawings, our engineer will come out

with the suitable technical proposal with the basic machine concept drawings to you. Be size after you

placing the order we will send you the more detailed design drawings of the machine to you for confirmation.

Only after you confirming the drawings then we will start the manufacturing process.

Q7: what’s your payment terms?
Answer: we can accept the following payment terms: T/T, L/C, Western Union, Alibaba trade assurance.

(we prefer you to choose the Alibaba trade assurance order. If you are not satisfied with the machine that

you order, or we delay the shipping time, then you can apply the complaint on alibaba.com. )

Q8: how can we install the machine?
Answer: for some simple machines we will provide you the english operation manual, the operation video

and also we will provide you the online guidance and training to your engineer so you can set up the

machine easily. For some complicated machines, we will send engineer to your country to help installation

and training. But there will be extra cost for Engineer, including the salary, visa cost, round-trip ticket

cost, and accommodation fee will be covered by the buyer.
