Mexico Popular R101 Trapezoidal Roof Sheet Roll Forming Machine With Chain Drive And Thickness Calibre 26

Thickness Calibre 26 Mexico Popular Lamina R101 Trapezoidal Roof Sheet Roll Forming Machine

The R101 sheet model is a rectangular steel sheet that has 7 channels that make up its profile. The use of a sheet like this is found in roofs, industrial warehouses and in enclosures that need a stable structural capacity with a good drainage system for roofs.

Technical parameter:

Rolling Speed: 0-10m/min

Feeding width: 1219mm

Steel sheet Thickness: 0.3-0.8mm galvanized sheet

Control System: PLC Siemens

Roller Stations: about 24 stations

Roller Material : 45# forge steel, coated with chrome

Shaft Material and DIA: ￠75mm,material is 45# forge steel, Chrome with quenching

Motor Power: 7.5kw main motor

Hydraulic power: 4kw

Hydraulic Pressure: 12Mpa

Tolerance: +1.5mm

Power supplier: 220V or 480V

Way Of Drive: chain

The main products of factory is light gauge framing machine, pre-painted steel forming machine, Glazed Tile forming machine, Automatical C/Z Purlin forming machine, Floor Deck forming machine, Guardrail forming machine, Down Pipe forming machine, The whole carriage plate for car beam unit , Steel storage unit, etc. Totally it has 100 types in 20 serious. The products are widely used in warehouse, factory buildings, supermarket, Nursing homes, villas, residential, greenhouse and other construction projects. Our factory can meet the construction enterprises, automobile industry, iron and steel production enterprises’s growing demand.
